NZXT CASE H9 ELITE BLACK

Overview

Details

The H9 Elite is designed to show off every angle of your build with a tempered glass top panel and a built-in RGB & Fan Controller. The unique wraparound glass design with a dual-chamber layout is the perfect showcase for premium components.



Unique uninterrupted glass panel for a clear view of the interior

Intuitive cable management and dual chamber design

Room for ten fans or three 360mm Radiators

Tempered glass top panel and included RGB & Fan Controller

Direct airflow to the GPU for handling high-powered components

Enhanced experience with other products from the NZXT ecosystem

Includes three F Series 120mm RGB Duo Fans and one F120Q Fan

Inside the Box

H9 Elite Case x1



Front I/O split cables x1



120mm RGB Duo Fan x3



120mm Quiet Airflow Fan (Case Version) x1



RGB and Fan Controller x1



Installation Accessories x1



Manual x1





Tech Specs

KEY SPECS



Motherboard Support:Mini-ITX, Micro-ATX, ATX



Enclosure Type:Mid-Tower



Case Material:SGCC Steel, Tempered Glass



DIMENSIONS



Height:495mm (With Feet)



Width:290mm



Depth:466mm



Weight:13.1 kg



COMPATIBILITY & CLEARANCE



CPU Cooler Clearance:Up to 165mm



GPU Clearance:Up to 435mm



PSU Clearance:200mm



Cable Management:91mm



FRONT I/O PORTS



USB 3.2 Gen 1 Type-A:2



USB 3.2 Gen 2 Type-C:1



Headset Audio Jack:1



EXPANSION SLOTS



Standard:7



Vertical:0



DRIVE BAYS



2.5":4+2



3.5":2



FAN SUPPORT



Side:3 x 120mm



Top:3 x 120mm / 2 x 140mm



Bottom:3 x 120mm / 2 x 140mm



Rear:1 x 120mm



Filters:All Air Intakes



RADIATOR SUPPORT



Side:Up to 360mm



Top:Up to 360mm



Bottom:Up to 360mm



Rear:Up to 120mm



FAN SPECS



Model:F120Q (Case Version)



Speed:1200 ± 240RPM



Airflow:62.18 CFM



Static:1.05 mm - H2O



Noise:25.1 dBA



Fan Connector:3-pin



FAN SPECS



Model:F120RGB Duo



Speed:500 ± 1800RPM



Airflow:48.58 CFM



Static:2.42mm - H2O



Noise:29 dBA



Fan Connector:4-pin



GENERAL



Warranty:2 Years
