NZXT CASE H9 FLOW WHITE

Overview

Details

The H9 Flow is designed to cool off powerful GPUs with its expansive thermal capabilities, featuring the capacity for ten fans and numerous 360mm radiator mounting options and the perforated top panel takes cooling even further.

Unique uninterrupted glass panel for a clear view of the interior

Intuitive cable management and dual chamber design

Room for ten fans or three 360mm Radiators

Perforated top panel for enhanced cooling

Direct airflow to the GPU for handling high-powered components

Enhanced experience with other products from the NZXT ecosystem

Includes four F Series 120mm Quiet Airflow fans



Inside the Box

H9 Flow Case x1



Front I/O split cables x



120mm Quiet Airflow Fan (Case Version) x4



Installation Accessories x1



Manual x1



Tech Specs

KEY SPECS



Motherboard Support:Mini-ITX, Micro-ATX, ATX



Enclosure Type:Mid-Tower



Case Material:SGCC Steel, Tempered Glass



DIMENSIONS



Height:495mm (With Feet)



Width:290mm



Depth:466mm



Weight:12.1 kg



COMPATIBILITY & CLEARANCE



Max CPU Cooler Clearance:Up to 165mm



Max GPU Clearance:Up to 435mm



PSU Clearance:200mm



Cable Management:91mm



FRONT I/O PORTS



USB 3.2 Gen 1 Type-A:2



USB 3.2 Gen 2 Type-C:1



Headset Audio Jack:1



EXPANSION SLOTS



Standard:7



Vertical:0



DRIVE BAYS



2.5":4+2



3.5":2



FAN SUPPORT



Side:3 x 120mm



Top:3 x 120mm / 2 x 140mm



Bottom:3 x 120mm / 2 x 140mm



Rear:1 x 120mm



Filters:All Air Intakes



RADIATOR SUPPORT



Side:Up to 360mm with Push/Pull



Top:Up to 360mm



Bottom:Up to 360mm



Rear:Up to 120mm



FAN SPECS



Model:F120Q (Case Version)



Speed:1200 ± 240RPM



Airflow:62.18 CFM



Static:1.05 mm - H2O



Noise:25.1 dBA



Fan Connector:3-pin



GENERAL



Warranty:2 Years
